Universal Process Calibrator
UC-905 — Universal Calibrator
The UC-905 is a comprehensive, portable multifunction process calibrator for sourcing, simulating and measuring the full range of process signals. Calibrate temperature transmitters, pressure loops, 4-20mA instruments and HART devices — all from a single handheld unit. Rugged, battery-operated and designed for daily field use by instrumentation engineers.
Measure
V / mA / Ω / T/C / RTD
Source / Simulate
mA / mV / T/C / RTD
HART
Device communication
Accuracy
±0.02% of reading
Power
Li-ion battery (8hr)
Display
Backlit graphic LCD
Why UC-905?
One Tool.
Every Calibration.
Temperature Calibration
Simulate all common thermocouple types (J, K, R, S, T) and RTD PT-100 / PT-1000 — verify transmitters, indicators and controllers without a separate simulator.
4-20mA Source & Measure
Source a precise 4-20mA signal to test control loops, or measure an existing loop current to verify transmitter output — in one instrument.
HART Communication
Communicate with HART-enabled field devices for configuration, diagnostics and calibration without a separate HART communicator.
Built for Industry
Rugged construction, 8-hour battery life and backlit graphic LCD display — designed for daily use by field instrumentation teams in demanding industrial environments.
